4SFm4
Our cables and connectors are used in many different systems, applications and industries, and trusted by professionals, both large and small that use and install it within the many different applications and disciplines that they cover.
Keywords: 182 Series Components | 210 Series Components
Category:
Product description
- Description
- Components
- Performance
-
- Commodity name: 4SFm4
APPLICATIONS
● Water supply from wells or reservoirs
● Agricultural irrigation, livestock watering
● Mining industry, construction drainage and dewatering
● Industrial cooling and processing Water distribution and pressure boosting,Etc
OPERATING CONDITONS
● Flow: up to 24m³/h (400L/min)
● Head: up to 507m
● Maximum water temperature:35℃
● Maximum allowable amount of sand:2.5%
MOTOR AND PUMP
● Motor adapter in compliance with NEMA standard Oil filled rewindable motor
● Maximum immersion depth:120m
● Horse Power range:0.5HP(0.37kw)--10HP(7.5kw)
● -Single phase 220-240V/50Hz (Equip with start control box)
● -Three phase 380-415V/50Hz
● Class of Insulation:B
● Degree of Protection:IP 68WARRANTY:1 YEAR
● (According to our general sales conditions)
-
COMPONENTS MATERIAL Pump casing AISI 304SS/201SS Outlet Cast-Cu Inlet Cast-Cu Strainer AISI 304SS/201SS Diffuser PC Impeller POM Pump shaft AISI 304SS/201SS Shaft coupling AISI 304SS/201SS Motor casing AISI 304SS/201SS Mechanical seal Graphite-ceramic/TC Top chock Cast-Cu/Cast-iron Motor shaft AISI 304SS Bearing NSK/C&U Seal lubricant oil 10# White Oil -
PERFORMANCE TABLE
Type Motor power Outlet Delivery N≈2850r/ min 1~
220V-240V3~
380V-415VKW HP DN Q m³/h 0 0.6 1.2 1.8 2.4 3.0 3.6 4.2 4.8 5.4 6.0 6.6 l/ min 0 10 20 30 40 50 60 70 80 90 100 110 4SFm4/6 4SF4/6 0.37 0.5 1.5" H(m) 43 42 41 40 39 36 33 29 25 20 15 8 4SFm4/8 4SF4/8 0.55 0.75 1.5" 57 56 55 54 52 50 45 40 35 28 22 12 4SFm4/10 4SF4/10 0.75 1 1.5" 71 69 68 66 65 61 57 50 43 34 25 15 4SFm4/14 4SF4/14 1.1 1.5 1.5" 101 98 97 94 92 86 79 71 60 49 38 22 4SFm4/18 4SF4/18 1.5 2 1.5" 130 125 123 119 117 112 101 90 78 63 47 28 4SFm4/24 4SF4/24 2.2 3 1.5" 174 166 164 160 156 148 135 121 103 82 63 35 4SF4/32 3 4 1.5" 220 215 208 202 196 185 175 155 132 106 80 40 4SF4/42 4 5.5 1.5" 292 284 272 264 257 242 228 204 176 143 103 52 4SF4/58 5.5 7.5 1.5" 403 392 376 365 352 335 315 282 243 198 142 72 4SF4/72 7.5 10 1.5" 492 482 465 448 436 415 390 350 304 239 173 84 PACKAGING INFORMATION
Model
Single-phasePump body
size(cm)Pump body
weight(kg)Motor
size(cm)Motor
weight(kg)Whole pump
size(cm)Whole pump
weight(kg)4SFm4/6-0.37 40×10×10.5 5.0 33×11×11.5 7.4 71×11×11.5 11.0 4SFm4/8-0.55 46×10×10.5 4.1 35×11×11.5 8.8 80×11×11.5 12.9 4SFm4/10-0.75 52×10×10.5 4.5 37×11×11.5 9.6 88×11×11.5 14.1 4SFm4/14-1.1 67×10×10.5 6.0 43×11×11.5 11.7 108x11x11.5 17.7 4SFm4/18-1.5 82×10×10.5 7.3 48×11×11.5 14.1 129x11x11.5 21.5 4SFm4/24-2.2 103×10×10.5 9.1 57×11×11.5 18.3 158x11x11.5 27.8 Model
Three-phasePump body
size(cm)Pump body
weight(kg)Motor
size(cm)Motor
weight(kg)Whole pump
size(cm)Whole pump
weight(kg)4SF4/6-0.37 40×10×10.5 3.6 37×11×11.5 7.6 76×11×11.5 10.8 4SF4/8-0.55 46×10×10.5 4.1 40×11×11.5 8.9 84×11×11.5 12.9 4SF4/10-0.75 52x10x10.5 4.5 42×11×11.5 9.8 92×11×11.5 13.9 4SF4/14-1.1 67×10×10.5 6.0 47x11x11.5 11.8 113×11×11.5 17.3 4SF4/18-1.5 82×10×10.5 7.3 51×11×11.5 14.2 132×11×11.5 20.9 4SF4/24-2.2 103×10×10.5 9.1 55×11×11.5 15.9 156x11x11.5 26.9 4SF4/32-3 126×10×10.5 11.5 62×11×11.5 20.7 4SF4/42-4 168×10×10.5 15.3 70×11×11.5 24.3 4SF4/58-5.5 215x10x10.5 22.5 78×11×11.5 30.1 4SF4/72-7.5 262×10×10.5 27.7 85×11×11.5 34.2
APPLICATIONS
● Water supply from wells or reservoirs
● Agricultural irrigation, livestock watering
● Mining industry, construction drainage and dewatering
● Industrial cooling and processing Water distribution and pressure boosting,Etc
OPERATING CONDITONS
● Flow: up to 24m³/h (400L/min)
● Head: up to 507m
● Maximum water temperature:35℃
● Maximum allowable amount of sand:2.5%
MOTOR AND PUMP
● Motor adapter in compliance with NEMA standard Oil filled rewindable motor
● Maximum immersion depth:120m
● Horse Power range:0.5HP(0.37kw)--10HP(7.5kw)
● -Single phase 220-240V/50Hz (Equip with start control box)
● -Three phase 380-415V/50Hz
● Class of Insulation:B
● Degree of Protection:IP 68
WARRANTY:1 YEAR
● (According to our general sales conditions)
